OEM
VSP/08
2.0 Megapixel Starlight Face Capture IR IP PTZ Dome Camera
PTZ Camera, 2 Mega Pixel, Dome Camera, 30X Optical Zoom
2 Megapixel PTZ Cameras
Background:
VS Series PTZ Dome type Cameras are Industrial Grade for Outdoor / Indoor applications. Cameras are equipped with High Resolution 2 mega pixel sensor to monitor with high accuracy.
Differentiators
High resolution
Industrial Grade
Easy to Integrate
Quick Support
Solution
Video Surveillance Apllications
Features
VS231-P2 series 2.0 Megapixel Starlight Face Capture IR IP PTZ Dome Camera is specially designed for intelligent face capturing and recognition. The camera has a built-in HD integrated camera module, utilizes large size progressive scanning CMOS sensor and has an internal 30X optical zoom lens
Support
Infinova Tech Support Staff
Technical Specifications
- Built-in 30X HD integrated camera module
- Large area progressive scanning CMOS sensor
- ICR in
- frared filter type automatic switch to realize true day/night surveillance Inbuilt efficient infrared lamps of 850nm wave length to ensure stable long-term use and reduce maintenance cost
- Night vision distance up to 300 meters
- HD network video output: 1920×1080@60fps
- H.265/H.264/M-JPEG video encoding, quad video streams
- Features rich smart functions:
- 5 video anomaly detection: camera tampering, high brightness, low brightness, video loss and color cast
- 10 behavior-analysis detection: motion detection, wire crossing detection, intrusion detection, loitering detection, object abandoned detection, object lost detection, abnormal sound detection, crowd detection, fast moving detection, and fighting detection
- 1 statistics detection: crowd density detection
- 3 feature detection: face detection, vehicle detection, and human body detection
- Supports deep-learning based face detection, face tracking and capturing
- Supports snapshots optimization and duplicate deletion as per the face angle and the image definition so as to ensure the captured images can be recognized and reduce the number of the invalid images to upload to the server
- Supports image matting to provide small face image or large panoramic Images to be uploaded to the platform for secondary analysis and retrieval Able to detect human face when tilting up or down ±20°, turning right or left ±40°, or leaning right or left ±30°
- Able to detect human face with the minimum pupil distance of 20 pixels
- Able to detect 32 human faces simultaneously in a scene
- Supports intelligent tracking
- Supports embedded storage (dual SD card)/NAS storage
- Bi-directional audio, G.711-A/G.711-U/G.726/AAC standard optional
- Two alarm inputs and one alarm output
- Supports multiple ways to trigger alarms, such as I/O input, intelligent detection, SD card removal, SD card full, network disconnection, heartbeat loss, etc.; supports flexible alarm associated configurations, such as I/O output, email, FTP uploading, audio, SD card recording, SD card snapshot, alarm info push and PTZ tracking; supports arming by time
- Supports Region of Interest (ROI), 8 regions dividable
- Supports preset, autopan, pattern, autoscan, timed tour, normal tour, scene tour, power-on return, etc.
- Allows multiple users to perform live access and parameters settings via Web Server
- Standard SDK, easy to integrate with other digital system
- Supports ONVIF Profile S & Profile G standard
- Supports RS485 control and analog video output for easy debugging
- IP66 protection rate, inbuilt a heater and air circulation system to avoid icing
Target Clients
Industries, Hotels, Universities, Smart Cities, Airports and Railways etc
