Scope

Technical Specifications

1. 1/3" CMOS sensor
2. IR-Cut Removable (ICR) Filter for Day/Night switching
3. 50m IR distance
4. Uses Smart-IR technology; auto-adjusts IR lamp power according to ambient illumination
5. Supports multi-frame integration WDR, with dynamic range up to 120dB
6. Smart functions, such as premier protection (including cross-line and area intrusion detection), and feature protection (scene change, defocus, color cast, low brightness, and high brightness detection)
7. Built-in motorized zoom lens, supporting assistant focusing
8. H.265+M-JPEG or H.264+M-JPEG video encoding, three streams
9. Maximum resolution supports 2592×1520@20fps/2560×1440@25fps
10. Bi-directional audio, G.711a/G.711u/ACC
11. Supports corridor mode
12. Local PC recording
13. Supports TF card storage/NAS storage
14. Support alarm recording and event recording (including network disconnection)
15. Supports alarm snapshot and event snapshot
16. Supports multiple alarm trigger methods such as I/O input, broken network, motion detection, video tampering, smart analyzing, etc.; supports flexible alarm association settings like I/O output, emails, FTP picture uploading, audio, TF card recording and alarm information push
17. Up to 8 ROI (Region of Interest) areas
18. Up to four definable motion detection areas
19. Up to four definable privacy mask areas
20. Supports live access and parameter setting via Web Server from multiple users
21. Compatible with digital video surveillance software like Infinova V2216
22. Standard SDK provided for easy integration with other video surveillance software
23. ONVIF Profile Q, S, G & T compliant
24. New structure design, surface mount; bracket mount can be achieved when using installation accessories
25. 3-axis adjustment
26. IP66 rating
27. Rugged design (IK10)
28. PoE/12VDC/24VAC
